TRAILER OVERVIEW
This heavy‑duty dump trailer is built on a 10,000‑lb GVWR platform with a rugged channel‑frame design, scissor hoist, and 5,200‑lb Dexter braking axles for reliable performance. It includes premium features like LED lighting, a two‑way tailgate, slide‑in loading ramps, a lockable toolbox, and a full tarp system, making it ready for demanding hauling jobs.
ADDITIONAL SPECS
Model: LPTH
GVWR: 10,000 lb.
Capacity: 7,000 lb.
Axles: 5,200 lb. Dexter Brand Braking Axles with Double Eye Suspension
Frame/Dimensions:
6″ Channel Main Frame – 6″ Channel Tongue
3×3 Tubing Dump Box Frame
3″ Channel Crossmembers on 16″ Centers
12 Gauge Floor & Wall
30″ Headboard With 24″ Sides
72″ Inside Width
Hydraulics: US Made Pump With 20′ Hand Remote, (Optional Wireless Remote) Deep Cycle Battery
Scissor Hoist (Power Up Power Down)
Tailgate: Two Way Tailgate Opens for Dumping Bulk Materials or Can Be Set in Spreader Mode
Coupler: 2 5/16″ Adjustable Coupler k
Jack: 5,000 Ib. Side Wind Jack
Paint: Phosphate Washed, Primed with Epoxy Primer and Two Coats of Polyurethane Paint
Standard Features:
Lockable Toolbox with Tool Divider
(4) D-Rings mounted to Wall on Inside of Dump Box
Tarp System With Aluminum Pull Bar
Spare Tire Mount
